Piston Check Valve, Threaded, PN 40
SIZE : 1/4″~2″
END CONNECTION : SCREWED - BS21 1973 (BSPT), ANSI B2.1 (NPT), DIN 259/2999, ISO 228
MAX. PRESSURE : PN 40 (42kg/cm²)
MAX. TEMPERATURE: 230℃ (446℉)
MATERIAL : ASTM A351-CF8M (1.4408) / ASTM A351-CF8 (1.4308)
- INVESTMENT CASTING BODY & CAP
- THE END-TO END LENGTH CONFORMS TO DIN 3202, PART 4
- M8 SERIES (PN40)
